HIK DS-PEA22-F(B) Video Panic Alarm Panel

HIK DS-PEA22-F(B) Video Panic Alarm Panel

Video Panic Alarm Panel

  • One-touch emergency calling
  • High quality imaging with 2 MP built-in camera
  • Real-time security via sound and voice detection
  • Supports broadcasting
  • Supports dual net ports
  • Built-in SD slot supports MicroSD / SDHC / SDXC up to 128 GB
  • Supports siren and audio expansion

Available models:

DS-PEA22-F(B)

Product Data

  • Detection performance
  • Sound pressure110dB, Sound Can be Configured Separately
  • Software features
  • Tamper-Prooftamper alarm
  • Intercom1-ch Built-in Omnidirectional Microphone, Pickup Distance: 5 m
  • ProtocolTCP/IP, RTSP, SNMP, HIK-SIP, Standard SIP, ONVIF
  • Hardware features
  • Alarm input2
  • Alarm output2
  • Netowrk interface1RJ45,10 M/100 M/1000 M self adaptive
  • Audio interface

    1-ch Built-in Omnidirectional Microphone, Pickup Distance: 5 m

    1-ch 3.5 mm Audio Interface for External Audio Input
  • PSTN1
  • BusRS-485 1, Half-duplex
  • SD CardStandard Micro SD card Slot, Supports Micro SD/SDHC/SDXC Card, Max. 128G
  • Video
  • Resolusion1920*1080
  • Frame rate25fps
  • Field Angle

    Horizontal: 128°

    Vertical: 75°

    Diagonal: 147°
  • Day/night switch modeIR Cut Filter
  • Audio
  • Audio input

    1-ch Built-in Omnidirectional Microphone, Pickup Distance: 5 m

    1-ch 3.5 mm Audio Interface for External Audio Input
  • Audio output

    1-ch 30 W Build-in Loudspeaker

    1-ch 3.5 mm Audio Interface for External Audio Output
  • Audio compression code rate16Kbps;64Kbps
  • Electrical characteristics
  • Power supply12VDC
  • Power Consumption ≿24 W
  • Wireless transmission
  • Wired network10 M/100 M Self-adaptive Ethernet port
  • General
  • Operation temperature-40 °C to +60 °C (-40 °F to 140 °F)
  • Operation humidity10% to 90%
  • Dimension(WxHxD)218 mm × 128 mm × 58 mm (8.58" × 5.04" × 2.28")
  • Installation methodWall Mounting
  • Device management
  • Camera2 MP HD IR Camera
,
  • Sound pressure110dB, Sound Can be Configured Separately
,
  • Tamper-Prooftamper alarm
  • Intercom1-ch Built-in Omnidirectional Microphone, Pickup Distance: 5 m
  • ProtocolTCP/IP, RTSP, SNMP, HIK-SIP, Standard SIP, ONVIF
,
  • Alarm input2
  • Alarm output2
  • Netowrk interface1RJ45,10 M/100 M/1000 M self adaptive
  • Audio interface

    1-ch Built-in Omnidirectional Microphone, Pickup Distance: 5 m

    1-ch 3.5 mm Audio Interface for External Audio Input
  • PSTN1
  • BusRS-485 1, Half-duplex
  • SD CardStandard Micro SD card Slot, Supports Micro SD/SDHC/SDXC Card, Max. 128G
,
  • Resolusion1920*1080
  • Frame rate25fps
  • Field Angle

    Horizontal: 128°

    Vertical: 75°

    Diagonal: 147°
  • Day/night switch modeIR Cut Filter
,
  • Audio input

    1-ch Built-in Omnidirectional Microphone, Pickup Distance: 5 m

    1-ch 3.5 mm Audio Interface for External Audio Input
  • Audio output

    1-ch 30 W Build-in Loudspeaker

    1-ch 3.5 mm Audio Interface for External Audio Output
  • Audio compression code rate16Kbps;64Kbps
,
  • Power supply12VDC
  • Power Consumption ≿24 W
,
  • Wired network10 M/100 M Self-adaptive Ethernet port
,
  • Operation temperature-40 °C to +60 °C (-40 °F to 140 °F)
  • Operation humidity10% to 90%
  • Dimension(WxHxD)218 mm × 128 mm × 58 mm (8.58" × 5.04" × 2.28")
  • Installation methodWall Mounting
,
  • Camera2 MP HD IR Camera
$1,000,000.00
HIK DS-PEA22-F(B) Video Panic Alarm Panel—
$1,000,000.00

Product Information

Shipping & Returns

Description

Video Panic Alarm Panel

  • One-touch emergency calling
  • High quality imaging with 2 MP built-in camera
  • Real-time security via sound and voice detection
  • Supports broadcasting
  • Supports dual net ports
  • Built-in SD slot supports MicroSD / SDHC / SDXC up to 128 GB
  • Supports siren and audio expansion

Available models:

DS-PEA22-F(B)

Product Data

  • Detection performance
  • Sound pressure110dB, Sound Can be Configured Separately
  • Software features
  • Tamper-Prooftamper alarm
  • Intercom1-ch Built-in Omnidirectional Microphone, Pickup Distance: 5 m
  • ProtocolTCP/IP, RTSP, SNMP, HIK-SIP, Standard SIP, ONVIF
  • Hardware features
  • Alarm input2
  • Alarm output2
  • Netowrk interface1RJ45,10 M/100 M/1000 M self adaptive
  • Audio interface

    1-ch Built-in Omnidirectional Microphone, Pickup Distance: 5 m

    1-ch 3.5 mm Audio Interface for External Audio Input
  • PSTN1
  • BusRS-485 1, Half-duplex
  • SD CardStandard Micro SD card Slot, Supports Micro SD/SDHC/SDXC Card, Max. 128G
  • Video
  • Resolusion1920*1080
  • Frame rate25fps
  • Field Angle

    Horizontal: 128°

    Vertical: 75°

    Diagonal: 147°
  • Day/night switch modeIR Cut Filter
  • Audio
  • Audio input

    1-ch Built-in Omnidirectional Microphone, Pickup Distance: 5 m

    1-ch 3.5 mm Audio Interface for External Audio Input
  • Audio output

    1-ch 30 W Build-in Loudspeaker

    1-ch 3.5 mm Audio Interface for External Audio Output
  • Audio compression code rate16Kbps;64Kbps
  • Electrical characteristics
  • Power supply12VDC
  • Power Consumption ≿24 W
  • Wireless transmission
  • Wired network10 M/100 M Self-adaptive Ethernet port
  • General
  • Operation temperature-40 °C to +60 °C (-40 °F to 140 °F)
  • Operation humidity10% to 90%
  • Dimension(WxHxD)218 mm × 128 mm × 58 mm (8.58" × 5.04" × 2.28")
  • Installation methodWall Mounting
  • Device management
  • Camera2 MP HD IR Camera
,
  • Sound pressure110dB, Sound Can be Configured Separately
,
  • Tamper-Prooftamper alarm
  • Intercom1-ch Built-in Omnidirectional Microphone, Pickup Distance: 5 m
  • ProtocolTCP/IP, RTSP, SNMP, HIK-SIP, Standard SIP, ONVIF
,
  • Alarm input2
  • Alarm output2
  • Netowrk interface1RJ45,10 M/100 M/1000 M self adaptive
  • Audio interface

    1-ch Built-in Omnidirectional Microphone, Pickup Distance: 5 m

    1-ch 3.5 mm Audio Interface for External Audio Input
  • PSTN1
  • BusRS-485 1, Half-duplex
  • SD CardStandard Micro SD card Slot, Supports Micro SD/SDHC/SDXC Card, Max. 128G
,
  • Resolusion1920*1080
  • Frame rate25fps
  • Field Angle

    Horizontal: 128°

    Vertical: 75°

    Diagonal: 147°
  • Day/night switch modeIR Cut Filter
,
  • Audio input

    1-ch Built-in Omnidirectional Microphone, Pickup Distance: 5 m

    1-ch 3.5 mm Audio Interface for External Audio Input
  • Audio output

    1-ch 30 W Build-in Loudspeaker

    1-ch 3.5 mm Audio Interface for External Audio Output
  • Audio compression code rate16Kbps;64Kbps
,
  • Power supply12VDC
  • Power Consumption ≿24 W
,
  • Wired network10 M/100 M Self-adaptive Ethernet port
,
  • Operation temperature-40 °C to +60 °C (-40 °F to 140 °F)
  • Operation humidity10% to 90%
  • Dimension(WxHxD)218 mm × 128 mm × 58 mm (8.58" × 5.04" × 2.28")
  • Installation methodWall Mounting
,
  • Camera2 MP HD IR Camera
