HIK DS-C60S-04HI HDMI Input Board
HDMI Input Board
- Supports 4 channels of 2K HDMI signal input and YUV 444 collection.
- Supports HDMI composite audio input.
Available models:
Data sheet
- Chassis
- Occupied SlotInput slot
- Audio Input
- Audio Input Interfaces4
- Audio Input Interface TypeHDMI composite audio
- Audio Sampling Rate32K / 48K sampling rate
- Audio ChannelDual channel
- Video Input
- Video Input Interface TypeHDMI 1.4
- Video Input Interfaces4
- Max. Video Input Resolution1080p
-
Video Input Resolution
1024 × 768@60 Hz, 1280 × 1024@60 Hz, 1366 × 768@60 Hz, 1440 × 900@60 Hz,
1680 × 1050@60 Hz, 1280 × 960@60 Hz, 1600 × 1200@60 Hz, 1280 × 720p@50 Hz,
1280 × 720p@60 Hz, 1920 × 1080p@50 Hz, 1920 × 1080p@60 Hz, 1920 × 1200@60 Hz
Custom resolution: width in the range of 800 to 2560, height in the range of 600 to 2560, width × height in the range of 800 × 600 × 60 to 2048 × 1152 × 60
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
HDMI Input Board
- Supports 4 channels of 2K HDMI signal input and YUV 444 collection.
- Supports HDMI composite audio input.
Available models:
Data sheet
- Chassis
- Occupied SlotInput slot
- Audio Input
- Audio Input Interfaces4
- Audio Input Interface TypeHDMI composite audio
- Audio Sampling Rate32K / 48K sampling rate
- Audio ChannelDual channel
- Video Input
- Video Input Interface TypeHDMI 1.4
- Video Input Interfaces4
- Max. Video Input Resolution1080p
-
Video Input Resolution
1024 × 768@60 Hz, 1280 × 1024@60 Hz, 1366 × 768@60 Hz, 1440 × 900@60 Hz,
1680 × 1050@60 Hz, 1280 × 960@60 Hz, 1600 × 1200@60 Hz, 1280 × 720p@50 Hz,
1280 × 720p@60 Hz, 1920 × 1080p@50 Hz, 1920 × 1080p@60 Hz, 1920 × 1200@60 Hz
Custom resolution: width in the range of 800 to 2560, height in the range of 600 to 2560, width × height in the range of 800 × 600 × 60 to 2048 × 1152 × 60
