HIK DS-C60S-02HO/4K HDMI Output Board(4K)
HDMI Output Board(4K)
- The 4K HDMI output board supports YUV 444 output and 2 channels of 4K 30 fps HDMI output or 1 channel of 4K 60 fps HDMI output.
- Supports composite audio output.
Available models:
Data sheet
- Chassis
- Occupied SlotOutput slot
- Video Output
- Video Output Interface TypeHDMI 2.0
- Video Output Interfaces2
- Max. Video Output Resolution4K
-
Video Output Resolution
4096 × 2160@60 Hz, 3840 × 2160@60 Hz, 4096 × 2160@30 Hz, 3840 × 2160@30 Hz, 2560 × 1600@60 Hz, 2560 × 1440@60 Hz, 1920 × 1200@60 Hz, 1920 × 1080@60 Hz
Supports LED screen, custom resolution output, 60 Hz loading output, and 8.8 MP loading with width ranging from 288 to 8192 and height ranging from 288 to 4320.
Supports LED screen, custom resolution output, 60 Hz loading output, and 2.6 MP loading with width ranging from 288 to 3840 and height ranging from 288 to 2160.
-
Loading Capacity for Video Output to LED
Single mesh port with load 8800000,
Width 288-8192;
Height 288-4320;
- Audio Output
- Audio Output Interface TypeHDMI composite audio
- Audio Output Interfaces2
