HIK DS-K1T690MW Ultra Face Recognition Terminals
Ultra Face Recognition Terminals
- Android system with deep learning algorithm
- 15.6-inch LCD touch screen, 2 MP wide-angle dual-lens
- 100,000 face capacity, 150,000 card capacity, and 150,000 event capacity
- Multiple authentication modes, including face, card, etc.
- Face recognition duration ≤ 0.2 s/User; face recognition accuracy rate ≥ 99%
- Supports mask wearing detection
- Supports single person and multiple people (Up to 5 people) recognition
- Connects to secure door control unit via RS-485 protocol to avoid the door opening when the terminal is destroyed
- Connects to external access controller or Wiegand card reader via Wiegand protocol
- Two-way audio with client software, door station, indoor station, and main station
- Supports the third-party application importing. Up to 9 applications and 120 M for each can be imported. For details, see the user manual
Available models:
DS-K1T690MW
Data sheet
- Display
- Screen size15.6 inch
- Operation methodCapacitive touch screen, gesture recognition is available
- TypeIPS
- Video
- Lens2
- Resolution2 MP
- FOVHFOV = 88°; VFOV = 44°; DFOV = 108°
- Audio
- Audio qualityNoise suppression and echo cancellation
- Network
- Wired networkSupport
- Wi-FiSupport, 2.4 G, 802.11b/g/n
- Interface
- Network interface2 RJ-45, 10/100/1000 M self-adaptive
- Lock control1
- Exit button1
- Door contact input1
- Alarm input2
- Alarm output1
- TAMPER1
- RS-4851 RS-485 (Half duplex, HIKVISION)
- Wiegand1 Wiegand(Hik 26bit,Hik 34bit)
- USB1
- Authentication
- Card typeM1 card
- Card reading frequency13.56 MHz
- General
- Power supply12 VDC to 24 VDC, 4 A
- Working temperature-30 °C to 60 °C (-22 °F to 140 °F)
- Working humidity10 to 90% (No condensing)
- Dimensions432 mm × 251 mm × 35 mm (17.0" × 9.9" × 1.4")
- InstallationWall mounting, base mounting, and bracket mounting
- LanguageEnglish
- PlatformHik-ProConnect and HikCentral Professional
- Function
- Face anti-spoofingSupport
$3,500.00
Original: $10,000.00
-65%HIK DS-K1T690MW Ultra Face Recognition Terminals—
$10,000.00
$3,500.00Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Ultra Face Recognition Terminals
- Android system with deep learning algorithm
- 15.6-inch LCD touch screen, 2 MP wide-angle dual-lens
- 100,000 face capacity, 150,000 card capacity, and 150,000 event capacity
- Multiple authentication modes, including face, card, etc.
- Face recognition duration ≤ 0.2 s/User; face recognition accuracy rate ≥ 99%
- Supports mask wearing detection
- Supports single person and multiple people (Up to 5 people) recognition
- Connects to secure door control unit via RS-485 protocol to avoid the door opening when the terminal is destroyed
- Connects to external access controller or Wiegand card reader via Wiegand protocol
- Two-way audio with client software, door station, indoor station, and main station
- Supports the third-party application importing. Up to 9 applications and 120 M for each can be imported. For details, see the user manual
Available models:
DS-K1T690MW
Data sheet
- Display
- Screen size15.6 inch
- Operation methodCapacitive touch screen, gesture recognition is available
- TypeIPS
- Video
- Lens2
- Resolution2 MP
- FOVHFOV = 88°; VFOV = 44°; DFOV = 108°
- Audio
- Audio qualityNoise suppression and echo cancellation
- Network
- Wired networkSupport
- Wi-FiSupport, 2.4 G, 802.11b/g/n
- Interface
- Network interface2 RJ-45, 10/100/1000 M self-adaptive
- Lock control1
- Exit button1
- Door contact input1
- Alarm input2
- Alarm output1
- TAMPER1
- RS-4851 RS-485 (Half duplex, HIKVISION)
- Wiegand1 Wiegand(Hik 26bit,Hik 34bit)
- USB1
- Authentication
- Card typeM1 card
- Card reading frequency13.56 MHz
- General
- Power supply12 VDC to 24 VDC, 4 A
- Working temperature-30 °C to 60 °C (-22 °F to 140 °F)
- Working humidity10 to 90% (No condensing)
- Dimensions432 mm × 251 mm × 35 mm (17.0" × 9.9" × 1.4")
- InstallationWall mounting, base mounting, and bracket mounting
- LanguageEnglish
- PlatformHik-ProConnect and HikCentral Professional
- Function
- Face anti-spoofingSupport
