HIK DS-3E0524-E(B) 24 Port Gigabit Unmanaged Switch
24 Port Gigabit Unmanaged Switch
- 24 x 1000M Ethernet ports
- Supports IEEE 802.3, IEEE 802.3u and IEEE 802.3x
- 1000M network access
- Wire-speed forwarding and non-blocking design
- Store-and-forward switching
- Solid high-strength metal shell
- Fan-free design with high reliability
Available models:
DS-3E0524-E(B)
Product Data
- Network Parameters
- Ports24 × Gigabit RJ45 ports
- Port TypeRJ45 port, Full duplex, MDI/MDI-X adaptive
- StandardIEEE 802.3, IEEE 802.3u, IEEE 802.3x
- Forwarding ModeStore-and-forward switching
- MAC Address Table8 K
- Switching Capacity48 Gbps
- Packet Forwarding Rate35.712 Mpps
- Internal Cache4.1 Mbits
- General
- Dimensions (W × H × D)335 mm × 44.5 mm × 175.8 mm
- ShellMetal material, fan-free design
- Gross Weight2.47 kg (5.44 lb)
- Net Weight1.60 kg (3.50 lb)
- Operating Temperature0 °C to 40 °C (32 °F to 104 °F)
- Storage Temperatureâ€? °C to 85 °C (â€? °F to 185 °F)
- Storage Humidity5% to 95% (no condensation)
- Power Supply220 VACï¼?0/60 Hz＿Max. 0.7 A
- Approval
- EMCFCC (ANSI C63.4, 47 CFR PART 15B); CE-EMC/RCM (EN 55032: 2015+A11:2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4:2011+A1:2014, EN 55035:2017+A11:2020); IC (ICES-003: Issue 14)
- SafetyUL (UL 62368-1); CB/RCM (IEC 62368-1:2014); CE-LVD (EN 62368-1:2014+A11:2024)
- ChemistryCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2013)
- Ports24 × Gigabit RJ45 ports
- Port TypeRJ45 port, Full duplex, MDI/MDI-X adaptive
- StandardIEEE 802.3, IEEE 802.3u, IEEE 802.3x
- Forwarding ModeStore-and-forward switching
- MAC Address Table8 K
- Switching Capacity48 Gbps
- Packet Forwarding Rate35.712 Mpps
- Internal Cache4.1 Mbits
- Dimensions (W × H × D)335 mm × 44.5 mm × 175.8 mm (13.2‿Ã?1.8‿Ã?6.9â€?/span>
- ShellMetal material, fan-free design
- Gross Weight2.47 kg (5.44 lb)
- Net Weight1.60 kg (3.50 lb)
- Operating Temperature0 °C to 40 °C (32 °F to 104 °F)
- Storage Temperatureâ€? °C to 85 °C (â€? °F to 185 °F)
- Storage Humidity5% to 95% (no condensation)
- Power Supply220 VACï¼?0/60 Hz＿Max. 0.7 A
- EMCFCC (ANSI C63.4, 47 CFR PART 15B); CE-EMC/RCM (EN 55032: 2015+A11:2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4:2011+A1:2014, EN 55035:2017+A11:2020); IC (ICES-003: Issue 14)
- SafetyUL (UL 62368-1); CB/RCM (IEC 62368-1:2014); CE-LVD (EN 62368-1:2014+A11:2024)
- ChemistryCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2013)
